ADLINK Ind. Touch Panel OM-215 21.5" Open frame, 1920x1080 16:9, FHD, PCAP, AF,400nits (w/i touch), Front IP65, with panel mounting clips
ADLINK Ind. Touch Panel OM-215 21.5" Open frame, 1920x1080 16:9, FHD, PCAP, AF,400nits (w/i touch), Front IP65, with panel mounting clips
- Brand: ADLINK
- MPN: 93-P6000-B310
- Part #: IPCADLOM215001
- UPC:
- Brand: ADLINK
- MPN: 93-P6000-B310
- Part #: IPCADLOM215001
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Industrial PCs & IoT
ADLINK Ind. Touch Panel OM-215 21.5" Open frame, 1920x1080 16:9, FHD, PCAP, AF,400nits (w/i touch), Front IP65, with panel mounting clips
- Brand: ADLINK
- MPN: 93-P6000-B310
- Part #: IPCADLOM215001
Product URL: https://www.pbtech.com/pacific/product/IPCADLOM215001/ADLINK-Ind-Touch-Panel-OM-215-215-Open-frame-1920x
Features
-
Key Features
- - 10.1"/15.6"/18.5"/21.5"/23.8"/27"/32"/43" (16:9) LCD panel with LED backlight with up to 50,000 service life
- - 10-point PCAP touchscreen (glove-use available)
- - Anti-fingerprint surface treatment for ease of cleaning and enhanced readability
- - Wide viewing angles supports both portrait and landscape modes
- - IP 65 rating for water and dust protection
- - Value added service (flexible customization)
- - Panel/ VESA/ Desktop Stand
Key Features
- - 10.1"/15.6"/18.5"/21.5"/23.8"/27"/32"/43" (16:9) LCD panel with LED backlight with up to 50,000 service life
- - 10-point PCAP touchscreen (glove-use available)
- - Anti-fingerprint surface treatment for ease of cleaning and enhanced readability
- - Wide viewing angles supports both portrait and landscape modes
- - IP 65 rating for water and dust protection
- - Value added service (flexible customization)
- - Panel/ VESA/ Desktop Stand
Smooth user interaction
ADLINK's projected capacitive technology supports 10-point multi-touch capabilities for smooth zoom, flick, rotate, swipe, drag, pinch, press, double tap, and other functions.
Immersive visuals
Easily adjust gamma correction, color saturation, brightness, contrast, and color balance with software programmable color management to reveal the true colors of stunning visuals.
High readability
ADLINK's industrial touch screen monitors are optimized for outdoor or semi-outdoor use thanks to their high brightness and sunlight readability features. The screen surface is treated with an anti-fingerprint solution to facilitate cleaning and maximize readability, and with wide-viewing angles available, these monitors support both portrait and landscape orientations.
High durability
Protected with 7H hardness and an IP65 front panel, ADLINK's industrial touch screen monitors can easily stand up to the hazards of harsh environments, such as water, dust ingress, scratches, abrasions, and metallic dust. On average, these monitors have a mean time before failure (MTBF) of up to 50,000 hours, minimizing maintenance costs.
Slim and light
The slim, light frame enables seamless integration and installation for any application.
Specifications
Display
Size
21.5"
Resolution
1920 x 1080
Aspect Ratio
16:9
Color
16.7M
Brightness (w/ touch)
400 nits
Backlight Life (Hrs)
30,000
Viewing Angle (U/D/R/L)
89/89/89/89
Contrast Ratio
1000:1
Touchscreen
10-point, PCAP, Anti-fingerprint coating
Bonding
Air bonding
I/O
USB Port
USB type B (for touch)
Video
HDMI x1, VGA x1
Audio
w/o Audio
Environmental
Operating Temperature
0°C to 60°C
Storage Temperature
-20°C to 60°C
Humidity
10% to 80% @ 40°C (non-condensing)
Surface Hardness
7H
Vibration
Operating: 1G random 5 to 500Hz
Shock
Operating: 20G acceleration part to part, 11ms
IP Rating
Front IP65
Power Input
DC-12V 5A Max.
Power Consumption
25.4 W
Mechanical
Net Weight/Gross Wegith
4.8 kgs /6.0 kgs
Packing Dimensions(H x W x D)
640 x 480 x160
Mounting
VESA Mount (MIS-D 75mm x 75mm,100mm x 100mm)Panel, and Wall mount
